Work Area (3-Axis): 360 mm (X) × 240 mm (Y) × 140 mm (Z)

Optional 4th Axis Work Area: 92 mm (diameter) × 240 mm (length)

Footprint (Machine Size): approx. 22.8 in × 20.5 in × 21.3 in

Gantry Clearance: 120 mm

Maximum Height (Lid Open): 84 cm

Spindle:

• Power: 200 W

• Speed: 0 – 15,000 RPM with closed-loop control

• Collet: built-in 1/8 in (with options such as 1/4 in, 6 mm, 4 mm)

• Cooling: Air-cooled, with support for external air assist

Tool Changer: 6-position automatic tool changer (ATC) — allows switching bits/tools automatically without manual intervention

Motion System:

• Ball screws with high-precision linear rails

• Servo motors for X/Y/Z axes, stepper motor for optional A-axis (4th axis)

• Maximum travel speed (rapid traverse): ~6000 mm/min

Precision:

• Spindle runout: < 0.01 mm

• Machine resolution / positioning: 0.01 mm

Dust Collection: Integrated dust-extraction system (with ~0.8 liter dust tank) to manage chips and debris during milling

Laser Engraving (optional module):

• Laser: 2.5 W diode laser (445 nm) — allowing engraving on wood, plastic, leather, fabric, etc.

Material Compatibility:

• CNC Milling: Wood (hardwood, softwood, MDF, plywood), plastics (PVC, ABS, acrylic, PC, HDPE, etc.), non-ferrous metals (aluminum, brass, copper), composites (carbon fiber, FR4), etc.

• Laser Engraving / Marking: Wood, plastic, leather, fabric, cardboard, and other suitable materials

Software & Connectivity:

• Controlled via dedicated software for Carvera functions

• Compatible with popular CAD/CAM software (e.g. Fusion 360, VCarve, SolidWorks, AutoCAD, Aspire, etc.)

• Connectivity: USB and Wi-Fi

Versatility & Functionality:

• Fully enclosed frame — safer, cleaner, and better for indoor/workshop use

• Automatic tool changing + auto-probing / auto-leveling (for surface irregularities) ensure precision and reduce setup work

• Supports 3-axis milling + optional 4th-axis rotary machining — enables cylindrical work, 4-sided parts, and more complex geometries

• Combines CNC milling and laser engraving in one machine — flexible for diverse projects

• Suitable for prototyping, small-series production, custom parts, artistic carving, PCB milling, engraving, and more

Use Cases: Ideal for makers, designers, engineers, hobbyists — useful for prototyping, custom fabrication, furniture parts, electronics enclosures, woodwork, plastic parts, PCB fabrication, engraving, art & craft, and small to medium scale manufacturing.
