Scanning Performance

• Scan Speed (Duplex):
  • Up to 280 images per minute (ipm) in A4 landscape at 200/300 dpi

• Scan Speed (Simplex):
  • Up to 140 pages per minute (ppm) in A4 landscape at 200/300 dpi
  • Up to 105 ppm in portrait mode at 200/300 dpi

• Optical Resolution: 600 dpi

• Output Resolutions: Adjustable from 50 to 600 dpi; up to 1200 dpi via driver

• Color Modes: Full color (24-bit), grayscale (8-bit), black & white (1-bit)

Document Handling

• Automatic Document Feeder (ADF) Capacity: 500 sheets (A4 / Letter)

• Document Sizes Supported:
  • Maximum: up to 304.8 × 431.8 mm (12 × 17 in)
  • Minimum: 52 × 74 mm (2 × 3 in)

• Long Document Scanning: Up to 5588 mm (220 in) in length in extended mode

• Paper Weight Range:
  • For A4–A5 sizes: 20–209 g/m² (5.4–56 lb)
  • For other sizes: 41–209 g/m² (11–56 lb)

• Multi-Feed Detection: Ultrasonic overlap and length sensing

• Paper Protection: Lag detection and reliable separation

Image Processing & Output

• Output File Types: PDF (standard and searchable), TIFF, multi-page TIFF, JPEG, JPEG2000, bitmap

• Image Enhancements: Auto color detection, blank page removal, deskew, edge correction, background smoothing, and dropout options

• Color Background Selection: White or black selectable for scan optimization

Connectivity & Interface

• Interface: USB 2.0 (backward compatible with USB 1.1)

• Driver Support: Standard scanner drivers and TWAIN/ISIS support for integration with most scanning applications

• Operating Environment: Designed for typical office conditions (cool to warm temperature and non-condensing humidity)

Physical Specifications

• Approximate Dimensions: Width ~18.1 in × Depth ~16.9 in × Height ~12.2 in

• Weight: Approx. 70 lb (32 kg) — scanner unit

• Power: AC 100–240 V (wide global compatibility)

• Power Consumption: Operating ~200 W or less; sleep ~3.2 W; standby ~0.3 W
