Scan Modes:

• HD Mode for small and medium objects

• Fast Mode for medium and large objects

Light Source:

• HD Mode: Infrared MEMS structured-light projection

• Fast Mode: Infrared VCSEL laser projection

Resolution / Point Distance:

• HD Mode: 0.05 mm – 3 mm

• Fast Mode: 0.5 mm – 10 mm

Scan Speed / Frame Rate:

• HD Mode: up to 15 FPS

• Fast Mode: up to 20 FPS

Working Distance:

• HD Mode: 100 – 350 mm

• Fast Mode: 350 – 1500 mm

Field of View:

• HD Mode: optimized for detail capture on small objects

• Fast Mode: wide field to support scanning large items

Texture Camera:

• Built-in 48 MP RGB color camera

• HD mode depth capture using dual 2 MP IR cameras

• Fast mode uses a 1.3 MP IR depth camera

Alignment Modes:

• Feature alignment

• Texture alignment

• Marker alignment

• Hybrid alignment

Output File Formats:

• STL, OBJ, PLY, ASC

Display & Interface:

• Integrated 6.4-inch 2K OLED touchscreen

• Wireless connection via Wi-Fi 6

• USB-C data interface

Processor & Memory:

• 8-core 2.4 GHz processor

• 32 GB RAM

• 512 GB internal SSD

• 32 GB eMMC system storage

Power & Battery:

• Built-in 5000 mAh battery

• Usage time: approximately 1.5 to 2 hours

• Supports PD and PPS fast charging

Physical Specifications:

• Dimensions: 180 × 95 × 26.5 mm

• Weight: approximately 535 g

Environmental Conditions:

• Operating temperature: –10 °C to 40 °C

• Operating humidity: 0% – 90% (non-condensing)
