Roland VersaEXPRESS RF 640

Home
Digital Printer
Roland VersaEXPRESS RF 640

Roland VersaEXPRESS RF 640

Price:

$8,500.00

SKU:

194524548

Brand:

Roland

Condition:

New

Weight:

0.00 LBS

Availability:

In Stock

Shipping:

Calculated at checkout

Product Description

Roland VersaEXPRESS RF-640

Advanced Imaging for Vibrant Colors with Sharp Details

The RF-640 delivers unsurpassed print performance. Brilliant photorealistic imaging at up to 1440 dpi with virtually no chromatic banding. Print speeds up to 521 sqft/hr.

Support for a wide array of coated and uncoated media. Indoor-safe GREENGUARD Gold-certified Eco-Sol MAX® 2 inks for a wider color gamut and increased density for rich, saturated colors. It all adds up to the smart choice for a wide range of applications, including signs and posters, banners, backlit displays, vehicle wraps and more.

Intelligent Features Save Time and Effort

With the RF-640, you’ll save time with intelligent features like the ability to replace inks without having to stop and restart the printer, an iPad app to remotely control common printer functions and Roland OnSupport for alerts e-mailed to your computer or mobile device. Be productive right from the start with an included take-up unit for unattended printing and VersaWorks® RIP software for advanced productivity. Now that's pure genius.

Advanced Print Technology

The VersaEXPRESS RF-640 is equipped with a gold-plated print head to reduce static and enable high quality imaging. Variable dot control produces droplets of seven different sizes for precise, detailed graphics, excellent photographic reproduction, smooth gradations and superb contrast. Roland Intelligent Pass Control precisely controls dot placement between passes, allowing the VersaEXPRESS RF-640 printer to produce smooth gradations, exceptional solid colors and optimal image quality in all print modes, including higher speeds

Mirrored Print Head Configuration

To ensure rich, consistent color at speeds of up to 521 square feet per hour, the RF-640 features a dual CMYK, mirrored print head (MYCKKCYM) that delivers rich, vibrant, consistent colors during bi-directional printing.

Achieve Superb Results with Eco-Sol MAX® 2 Inks

Award-winning Eco-Sol MAX 2 eco-solvent inks produces rich, vibrant colors that other inks simply can’t match. They dry quickly and provide unmatched long-term outdoor durability, scratch and chemical resistance, broad uncoated media support and a wide color gamut. GREENGUARD Gold certified, Eco-Sol MAX 2 inks meet some of the world's most rigorous standards for low emissions of VOCs into indoor air.

Integrated Two-Stage Heating System

The RF-640 features a built-in two stage integrated heater system designed to dry prints quickly – even in high-speed modes – for immediate collection by the take-up unit, finishing, and installation. This advanced system accommodates a wide range of media options and precisely controls the proper amount of heat for each application, yielding outstanding results every time.

VersaWorks RIP Included with Enhanced Productivity Tools

Roland VersaWorks is a user-friendly RIP software that helps RF-640 users achieve outstanding print results right out of the box. Using the latest Adobe® CSPI engine (3019), VersaWorks offers a host of advanced features that include a Predictive Ink Calculator, Spot Color Replacement, built-in Pantone® Spot Color Libraries, variable data printing, embedded ICC support, ink level adjustment tools, advanced cropping, tiling and nesting options, and much more. VersaWorks also includes the Roland Color System of more than 1000 spot colors for easy, effective color management.

Product Specification

Printing technology	Piezoelectric inkjet
Media	Width	10.2 to 64 in. (259 to 1625 mm)
	Thickness	Maximum 39 mil (1.0 mm) with liner
				Roll diameter	Maximum 8.3 in (210 mm)
	Roll weight	Maximum 88 lbs. (40 kg)
	Core diameter *1	3 in (76.2 mm) or 2 in (50.8 mm)
	Printing Width *2		Max. 63.6 in. (1615 mm)
Ink cartridges	Type	Roland Eco-Sol MAX 2 INK
	Capacity	440 cc
	Colors	Four Colors (cyan, magenta, yellow, and black)
Print resolution	Dots per in	Maximum 1,440 dpi
Print Modes	Resolution	Pass	Speed
Max Speed (Banner)	360x360	1	521 sqft/hr (49 m2/h)
Billboard (Banner)	360x720	2	289 sqft/hr (27 m2/h)
High Speed (Banner)	360x720	3	194 sqft/hr (18 m2/h)
Standard (Banner)	720x720	5	141 sqft/hr (13 m2/h)
High Quality (Banner)	1440x720	6	63 sqft/hr (6 m2/h)
High Speed (Vinyl)	360x720	3	199 sqft/hr (19 m2/h)
Standard (Vinyl)	540x720	5	141 sqft/h (13m2/h)
	720 x 720	6	117 sqft/hr (11m2/h)
High Quality (Vinyl)	1440x720	8	47 sqft/hr (4 m2/h)
Distance accuracy 3 4	Error of less than ±0.3percent of distance traveled, or ±0.3 mm, whichever is greater
Media heating system *5	Print heater	Setting range for the preset temperature: 30 to 45¼C (86 to 112¼F)
	Dryer	Setting range for the preset temperature: 30 to 50¼C (86 to 122¼F)
Connectivity	Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function	Automatic sleep feature
Power requirements	AC 100 to 120 V ±10percent, 8.2A, 50/60 Hz or
	AC 220 to 240 V ±10percent, 4.2A, 50/60 Hz
Power consumption	During operation	Approx. 1,070 W
	Sleep mode	Approx. 14.5 W
Acoustic noise level	During operation	64 dB (A) or less
	During standby	41 dB (A) or less
Dimensions (with stand)	101.4 (W) x 31.3 (D) x 50 (H) in (2,575 (W) x 795 (D) x 1,270 (H) mm)
Weight (with stand)	308.6 lbs. (140 kg)
Included items	Stand, power cord, media clamps, media holder, replacement sheet cutting blade, software RIP, user's manual, etc.

Roland VersaWorks System Requirements

Operating system	Windows® 8 (32-bit, 64-bit) Windows® 8.1 (32-bit, 64-bit) Windows® 7 (32-bit, 64-bit) Windows Vista® (32-bit, 64-bit) Windows® XP (32-bit, 64-bit)
CPU	Core™2 Duo, 2.0 GHz or faster recommended
RAM	2 GB or more recommended
Video card and monitor	A resolution of 1280 x 1024 resolution or more recommended
Free hard-disk space	40 GB or more recommended
Hard-disk file system	NTFS format
Optical drive	DVD-ROM drive
