Build & Printing

• Print Technology: Fused Filament Fabrication (FFF) / FDM

• Extruder System: Independent Dual Extruders (IDEX)

• Filament Diameter: 1.75 mm

• Maximum Print Speed: 200 mm/s

• Max Volumetric Speed: 16 mm³/s

• Nozzle Diameter (Default): 0.4 mm

• Optional Nozzle Sizes: 0.2 mm, 0.6 mm, 0.8 mm, 1.0 mm

• Max Nozzle Temperature: 330°C

• Layer Height Range: Approximately 0.1–0.5 mm (depending on nozzle)

Build Volume

• Single Extruder Mode: 330 × 240 × 240 mm (13 × 9.4 × 9.4 in)

• Dual Extruder Mode: 295 × 240 × 240 mm (11.6 × 9.4 × 9.4 in)

Mechanical & Bed Features

• Build Plate: Flexible double-sided PEI plate (default), optional flexible steel plate

• Heated Bed Max Temp: 110°C

• Leveling: Mesh automatic bed leveling with flatness detection

• Environmental Control: HEPA air filter with activated charcoal (for enclosure)

Connectivity & Interface

• Connectivity: Wi-Fi, LAN, USB

• Live Camera Support: Yes

• User Interface: 7-inch touchscreen display

• Supported File Types: STL, OBJ, 3MF, and more

• G-Code Compatible: Yes

Smart Features

• Auto Bed Leveling: Yes

• Power Loss Recovery: Yes

• Filament Run-out Sensor: Yes

• Substrate Printing Support: Yes

• Multiple Print Modes: Duplication, mirror, multi-material via IDEX

Materials Compatibility

Supports a wide range of materials including:

• Standard: PLA, ABS, ASA, PETG, TPU

• Composite: PET CF, PET GF, PPS CF, other composite filaments

• Engineering: PC, Nylon variants, PVA supports

• Flexible: TPU with auxiliary feeder

• Material profiles also supported via an open material program

Physical Specifications

• Machine Dimensions: 607 × 596 × 465 mm (23.9 × 23.5 × 18.3 in)

• Net Weight: 33.3 kg ≈ 73.4 lb

• Gross Weight (Carton Only): 42 kg ≈ 92.6 lb

• Gross Weight (Carton with Pallet): 49.5 kg ≈ 109.1 lb

Power Requirements

• Input Voltage: 100–240 V AC, 50/60 Hz

• Power Output: 24 V DC, 350 W
