Product Description

Introducing Graphtec's NEW CE7000 series cutting plotter. The NEW CE7000 model serves the garment decoration, sign graphics, PRINT and CUT graphics, automotive markets and many more.

The New CE7000 Series boasts our Popular Cutting Channel to allow easy perforated cut or through cut operations. The NEW CE7000 Series comes complete with our full complement of Graphtec Software along with our NEWLY ADDED Ethernet Connectivity. Cutting Master 4 plug-in for Adobe and Corel Users and our ever-Popular Graphtec Pro Studio software for design and cut graphics. The CE7000 series works with both PC and MAC platforms or use the handy new USB Thumb Drive Port if needed.

Product Specification

Specifications:

Maximum cutting area (W x L): 15" x 164'
Number of push rollers: 2
Maximum cutting speed: 24"/s, in all directions
Maximum acceleration: 69.6' (21.2 m/s²), at 45º direction
Maximum cutting force: 4.41 N (450 gf) in 38 steps
Maximum cutting area(W x L): 15" x 164'
Media type: Self-adhesive marking film (vinyl, fluorescent, reflective) excluding high-intensity reflective film, up to 25 mil (.63mm) cutting stencil material
Interface: USB 2.0 (Full Speed), Ethernet 10BASE-T/100BASE-TX
Buffer memory: 2 MB
Registration mark sensing system: Marks are scanned by an optical sensor (ARMS 8.0), Segment area and Multiple marks compensation, 4-points axis alignment, Auto mark detect
Alignment accuracy: Maximum 0.3 mm with printed image (when reading registration marks specified by this machine)
Power source: 100 to 120, 200 to 240 V AC (Auto switch), 50 / 60 Hz
Power consumption: 120 VA
External dimensions (W x D x H): Approx. 30.4" x 11.5" x 12.3"
Weight (Approx.): 27.7 lbs (13kg)
Compatible OS: Windows 10 / 8.1 / 7, Mac OSX 10.6 - 10.11 - 10.12 - 10.15
Included software: Cutting Master 4, Graphtec Pro Studio (for Windows), Graphtec Studio (for Mac), Windows driver
Has Contour Cutting: Yes
