Specifications:

• Printing Technology: PrecisionCore MicroTFP 4-channel, drop-on-demand printhead
• Ink Type: Epson T49M Ink Bottles (C, M, Y, K)
• Nozzles: 800 per channel, color & monochrome
• Droplet Tech: Variable Droplet Technology
• Max Resolution: 2400 x 1200 dpi
• Ink Volume: In-box: 140 mL x 2 (each color), Retail: 140 mL per bottle
• Shelf Life: 2 years (unopened), 6 months (opened)
• Ink Note: Use genuine Epson ink for best results

Media Handling

• Roll Width: Up to 24"
• Core Diameter: 2", user-adjustable
• Roll Cutting: Internal rotary cutter (auto/manual)
• Max Roll Diameter: 4.3"
• Media Thickness: Up to 8.6 mil
• Remaining Paper Display: On control panel
• Single Sheet Loading: Up to 24"
• Auto Sheet Feeder: 11" x 17" (50-sheet capacity)
• Min Sheet Size: Letter/A4
• Max Paper Width: 24.4"
• Margins: 0-3 mm (0.24" total)
• Max Print Length: Limited by OS/driver

Connectivity & UI

• Display: 4.3" touchscreen
• Interfaces: USB 3.0, Wireless LAN (802.11 b/g/n), Ethernet (1000/100/10 Base-T), Wi-Fi Direct®

System Compatibility

• Software: Epson Edge Print PRO (Windows 10, 8.1 64-bit)
• Drivers: macOS 10.7 – 14, Windows 10, 8.1

Size & Noise

• Without Stand: 38" x 32" x 10", 64 lb (29 kg)
• With Stand: 38" x 32" x 10", 84 lb (38 kg)
• Noise Levels: Operating: ~50 dB(A), Sleep: ~32 dB(A)

Operating Conditions

• Temperature: 50˚-95˚F (10˚-35˚C), Recommended: 65˚-75˚F (18˚-24˚C)
• Humidity: 20-80% (operating), 5-85% (storage)

Power & Compliance

• Voltage: 110-240V, 50-60Hz, 1.4A
• Power Consumption: Printing: ~22W, Ready: ~8W, Sleep: ~1.6W, Off: 0.2W
• Certifications: UL (MET), FCC (Class A), CSA, CE, EMC
